| 描述
|
思科 |
|
| 配置明文密码 |
enable pass |
set authentication password simole |
| 进入接口 |
interface type/number |
interface type/number |
| 进入vlan配置vlan管理地址 |
interface vlan1 |
interface vlan1 |
| 定义多个端口的组 |
interface range ethID to ID |
port-group 1 group-menber ethID to ID |
| 设置特权口令 |
enable secret |
super password |
| 配置接口状态 |
duplex（half/full/auto |
duplex（half/full/auto） |
| 配置端口速率 |
speed（10/100/1000) |
speed（10/100/1000) |
| 配置trunk |
switchport mode trunk |
port link-type trunk |
| 添加、删除vlan |
vlan ID/no vlan ID |
vlan batch ID/undo vlan batch ID |
| 将端口接入vlan |
switchport access vlan |
port default vlan ID |
| 查看接口 |
show interface |
display vlan ID |
| 封装协议 |
encapsulation |
link-protocol |
| 链路聚合 |
channel-group 1 mode on |
port link-aggregation group1 |
| 开启三层交换路由 |
ip routing |
默认开启 |
| 开启接口三层功能 |
no switchport |
undo portswitch |
| 对跨以太网交换机的VLAN进行动态注册和删除 |
vtp domain |
GVRP |
| stp配置根网桥 |
spannning-tree vlan ID root primary |
stp instance id root primary |
| 配置网桥优先 |
spanning-tree vlan ID priority |
stp primary vlaue |
| 查看stp |
show spanning-tree |
display stp brief |
| 引入路由信息 |
tribute |
import-route |
| 配置日志信息 |
logging |
info-center |
| 描述 |
思科 |
华为 |
| 配置默认路由 |
ip route 0.0.0.0 0.0.0.0 |
ip route-static 0.0.0.0 0.0.0.0 |
| 配置静态路由 |
ip route 目标网段 掩码 下一跳 |
ip route-static 目标网段 掩码 下一跳 |
| 查看路由表 |
show ip route |
display ip routing-table |
| 启用rip并宣告网段 |
route rip/network网段 |
rip/network网段 |
| 启用ospf |
route ospf |
ospf |
| 配置ospf区域 |
network ip 反掩码area |
area |
| 配置RIP v2水平分割 |
no auto-summary |
rip split-hotizon |
| 查看路由协议 |
show ip protocal |
display ip protocol |
| 标准访问控制列表 |
access-list 1-99 permit/deny ip |
rule id permit source IP |
| 拓展访问控 |
access-list 100-199 permit/deny protocol source IP+反码 destination ip+反码 operator operan |
rule{normal|special}{permit|deny}{tcp|udp}source{|any}destination{|any}|operate] |
| 配置HSRP组 |
vrrp group-number ip virtual-ip |
vrrp vrid number virtual-ip |
| 配置HSRP优先级 |
vrrp group-number priority |
vrrp vrid number priorty |
| 配置HSRP占先权 |
vrrp group-number preempt |
vrrp group-number preempt-mode |
| 配置端口跟踪 |
vrrp group-number rrack |
无 |
| 配置静态地址转换 |
ip nat inside sourec static |
nat server globalf[Port]insideport[protocol] |
| 描述 |
思科 |
华为 |
| 取消、关闭当前设置 |
no |
undo |
| 显示查看 |
show |
display |
| 退回上级 |
exit |
quit |
| 设置主机名 |
hostname |
sysname |
| 进入全局模式 |
en configter minal |
system-view |
| 删除文件 |
delete |
delete |
| 重启 |
reload |
reboot |
| 保存当前配置 |
write |
save |
| 创建用户 |
username |
local-user |
| 静止、关闭端口 |
shutdown |
shutdown |
| 显示当前系统版本 |
showversion |
display version |
| 查看已保存过的配置 |
show startup-config |
display current-configuration |
| 查看当前配置 |
show running-config |
display current-configuration |
| 取消所有debug命令 |
no debug all |
ctrl+d |
| 删除配置 |
erase startup-config |
reset saved-configuration |
| 退到用户视图 |
end |
return |
| 退出 |
exit |
logout |
| 指定信息中心配置信息 |
logging |
info-center |
| 进入线路配置（用户接口模式） |
line |
user-interface |
| 启动配置 |
start-config |
saved-configuration |
| 当前配置 |
running-config |
current-configuration |
| host名字和ip地址对应 |
host |
ip host |
| 设置VTY登录密码 |
line vty 0 4 |
user-interface vty 0 4 |
